Case CX75SR - Cx135 Sr with 2.39 M (7 Ft 10 In) Arm; Cx135 Sr with 2.85 M (9 Ft 4 In) Arm

CHAPTER 8 - SPECIFICATIONS
8-20
Issued 8-04 Bur 6-34551NA
CX135SR WITH 2.39 M (7 FT 10 IN) ARM
CX135SR WITH 2.85 M (9 FT 4 IN) ARM
IMPORTANT: Capacities marked with asterisk (*) are limited by hydraulic capacities.
Load (Lift)
Point
Height
Load Radius
End Side End Side End Side End Side End Side
5 ft. 10 ft. 15 ft. 20 ft.
Lb. Cap. at Max.
Reach
20 ft. 6 150* 6 150* 4 600* 4 600*
15 ft. 8 150* 8 150* 8 050* 7 100* 4 950* 4 300 3 200* 3 200*
10 ft. 14 400* 12 950 9 600 6 650 5 950 4 100 3 250* 3 250
5 ft. 17 950 11 350 9 000 6 100 5 700 3 900 3 600* 3 000
Ground
Level
17 000 10 550 8 550 5 700 5 500 3 700 4 200* 3 000
−5 ft. 11 450* 11 450* 16 800 10 400 8 350 5 550 5 400 3 600 5 000 3 350
−10 ft. 17 900* 17 900* 15 200* 10 600 8 400 5 600 6 450 4 350
−15 ft. 7 650* 7 650* 6 300 6 300
NOTE: 4 .73 m (15 ft. 6 in) Boom and 398 kg (879 lb.) bucket
Load (Lift)
Point
Height
Load Radius
End Side End Side End Side End Side End Side
5 ft. 10 ft. 15 ft. 20 ft.
Lb. Cap. at Max.
Reach
20 ft. 6 150* 6 150* 3 700* 3 700*
15 ft. 7 100* 7 100* 5 800* 4 400* 3 550* 3 550*
10 ft. 15 300* 15 300* 11 750* 11 750* 9 650* 6 800 6 000 4 200 3 650* 3 000
5 ft. 17 950* 11 650 9 100 6 200 5 750 3 950 4 000* 2 750
Ground
Level
17 000 10 600 8 550 5 700 5 450 3 700 4 100 2 750
−5 ft. 10 700* 10 700* 16 650 10 250 8 300 5 450 5 350 3 550 4 500 3 000
−10 ft. 16 300* 16 300* 16 650* 10 350 8 250 5 450 5 650 3 750
−15 ft. 10 500* 10 500* 7 350 6 300
NOTE:
4 .73 m (15 ft. 6 in) Boom and 338 kg (747 lb.) bucket
