CHAPTER 5 - LUBRICATION, FILTERS, AND FLUIDS
5-3
6-34551NA Issued 8-04 Bur
SERVICING INSTRUCTIONS
Respect the maintenance intervals by checking the
hourmeter every day. Before starting maintenance,
park the machine on flat, firm ground, away from any
obstacles, with the arm retracted and the bucket on
the ground. Unless otherwise specified, all
maintenance operations must be carried out with the
engine stopped, and the key removed from the
starter switch. It is preferable to wait for all circuits to
cool down before starting work.
Clean the grease fittings before lubrication. Clean
around plugs and filler holes before adding fluid. No
dust or dirt must enter the components or the circuits.
Wear suitable clothing and remember to use the
necessary safety equipment.
When carrying out service work on the machine,
place a Do Not Operate tag on the instrument panel.
Never climb down from the operator's compartment
leaving the engine running.
Any modification to this machine without prior
authorization could cause serious injury. Do not
make any modifications without authorization.
Consult your Dealer.
IMPORTANT: If you use your machine in particularly
harsh conditions (dusty or corrosive atmosphere,
etc.), the servicing intervals should be reduced
accordingly.
IMPORTANT: Take particular care to replace all
filters regularly. Clean filters mean longer engine
running life.
IMPORTANT: Oil and fluid should not be thrown on
the ground. They must be stored and removed by a
company which is responsible for their recycling or
their disposal.
SERVICE SPECIFICATIONS
Intervals between overhauls are much more frequent
for the following applications: construction of tunnels
using a hydraulic breaker, scale stripping, foundry
cleaning, operation under water etc. For special
applications consult your Dealer.
DAILY INSPECTIONS
Every day, before starting work, it is necessary to
inspect the machine and service certain of its
components.
GENERAL REMARKS
Check for water or oil leaks.
Check that all screws and nuts are correctly
tightened.
Wipe off any dust (engine, operator's
compartment, etc.).
Check for damage.
ENGINE
Check the oil level and change the oil if
necessary.
Check the coolant level.
Check for clogging or damage to the radiator.
Check the radiator fan belt tension.
Check the air filter is clean and not restricted.
Check for water or oil leaks on the components.
Check the condition of all lines.
UPPERSTRUCTURE
Check the fuel tank level.
Check the hydraulic reservoir level.
Check that the hydraulic oil is clean.
Check for water or oil leaks on the components.
Check the condition of all lines.
Check for electrical short-circuits.
Check the battery connections are properly
tightened.
Adjust the rear view mirrors.
UNDERCARRIAGE
Check the pad hardware.
Check the condition of the tracks.
WARNING: There is a risk of serious injury if
maintenance or repairs are not carried out
correctly. If you do not understand
maintenance procedures, consult your
Dealer.
WARNING: If the attachment is raised or if
the machine moves without an operator,
serious injury can result. Before performing
any maintenance, proceed as follows:
1. Park the machine on flat, level ground.
2. Lower the attachment until it is resting on
the ground.
3. Lower the dozer blade (if equipped) until
it rests on the ground.
4. Shut down the engine and remove the
starter key switch.
5. Lock the tracks to prevent any machine
movement.
WARNING: Be sure all the service
operations in this section are carried out
punctually at the intervals given, in order to
ensure optimum performance levels and
maximum safety when using the machine.
