CHAPTER 3 - INSTRUMENTS AND CONTROLS
3-27
6-34551NA Issued 8-04 Bur
CT02D285
Figure 79
Lift the hood to the maximum so that it gets locked
with the supporting prop.
CT02D287
Figure 80
To open the right-hand section (2), lift it manually
until it is folds back on the left-hand section (1).
NOTE: The left-hand section (1) has to be open to
lift section (2).
To close, operate the screw of the supporting prop
then pull down and slam the hood, both sections
close.
CT02D070
Figure 81
ENGINE HOOD
CX75SR, CX80
To open, press the button and lift the hood.
CT02C104
Figure 82
Lift the hood to the maximum so that it gets locked
with the compressed air cylinder.
To close, pull the hood down and slam it down to lock
it.
Use the key switch to lock the hood.
CT02C105
Figure 83
CX135SR
To open, pull the handle and lift the hood.
CT02C106
Figure 84
1
2
1
2
