CHAPTER 5 - LUBRICATION, FILTERS, AND FLUIDS
5-27
6-34551NA Issued 8-04 Bur
CT02D034
Figure 61
3. Open the drain plug located on the engine block.
NOTE: Have a receptacle of a suitable capacity
ready.
CT02D035
Figure 62
RINSING
1. Close the bleed plug when the radiator is
completely empty. Install the plug on the engine
block.
2. Fill the system with clean water. Install the
radiator cap.
3. Start the engine. Run the engine at a speed
slightly higher than idle speed for ten minutes to
bring the engine temperature up to about 80°C.
4. Drain the system once more.
5. Repeat Steps 1 to 4 until the water drained is
clear.
6. Install the panel under the upperstructure.
FILLING
1. Fill with coolant solution via the radiator until
overflowing and install the radiator cap.
CT02D033
Figure 63
2. Fill the expansion reservoir to the Full mark and
install the cap.
IMPORTANT: Use the correct coolant solution.
3. Run the engine at idle speed for about five
minutes. Add coolant solution if the level in the
expansion reservoir drops.
IMPORTANT: Do not fill the expansion reservoir
above the Full mark.
4. Close the hood then install the two thumb
screws.
CT02D032
Figure 64
