CHAPTER 5 - LUBRICATION, FILTERS, AND FLUIDS
5-21
6-34551NA Issued 8-04 Bur
CT02D031
Figure 42
5. Take a receptacle, place a pipe at the end (3),
loosen the screw (4) in order to drain the oil
cartridge (5).
CT02D011
Figure 43
6. Coat the seal of the new filter with a fine film of
oil.
7. Install the new filter. Turn the filter until the seal
comes into contact with the filter head then
tighten an extra half turn by hand.
IMPORTANT: Do not use a filter wrench to
tighten the filter. Excessive tightening can
damage the filter and their seals.
Fill the engine with new engine oil (9.6 liters).
Install the filling plug.
Run the engine for a few minutes and check that
there are no leaks. Check the level again and top
up if necessary.
IMPORTANT: Always wait fifteen minutes to allow
the oil to return to the sump before checking the oil
level.
CT02D301
Figure 44
2
3
5
4
