CHAPTER 5 - LUBRICATION, FILTERS, AND FLUIDS
5-23
6-34551NA Issued 8-04 Bur
CT02D020
Figure 49
5. Clean the area around the oil filters (3) and
remove them, using a filter wrench.
CT02D021
Figure 50
6. Coat the seal of the new filter with a fine film of
oil.
7. Install the new filters. Turn the filters until the
seals come into contact with the filter head then
tighten an extra half turn by hand.
IMPORTANT: Do not use a filter wrench to
tighten the filters. Excessive tightening can
damage the filters and the seals.
8. Fill the engine with new engine oil (15 liters).
Install the filling plug.
9. Run the engine for a few minutes and check that
there are no leaks. Check the level again and top
up if necessary.
NOTE: Always wait fifteen minutes to allow the
oil to return to the sump before checking the oil
level.
CT02D301
Figure 51
3
3
