CHAPTER 5 - LUBRICATION, FILTERS, AND FLUIDS
5-42
Issued 8-04 Bur 6-34551NA
CT02D113
Figure 117
CX135SR
To access the filter, remove the 4 screws and the
hood.
CT02D099
Figure 118
CT02D114
Figure 119
CHECKING THE HYDRAULIC SYSTEM LINES
Make sure there are no leaks from the hydraulic
system hoses, pipes, plugs, connections and fittings
and check that all nuts and screws are correctly
tightened. In the event of problems, repair, replace or
tighten the component(s) concerned.
