System Requirements
System Requirements
Bench and/or Fume Hood Space
The Liberty Blue should be positioned on the bench such that access to the electrical outlets for the system is not
restricted.
System Components Space Requirements
Liberty Blue Instrument (Discover Module and Liberty Blue Module):
20 in (50.8 cm) W x 21 in (53.3 cm) D x 30 in (76.2 cm) H
(Depth includes 3” (7.62 cm) clearance behind instrument for unimpeded airow at rear fan ducts)
CEM Supplied Controller:
15 in (38.1 cm) W x 10 in (25.4 cm) D x 16 in (40.6 cm)
(Height includes 14.1” (35.8 cm) display)
Environmental Conditions
The Liberty Blue is designed for indoor use only.
Temperature Range: 50 °F – 85 °F (10 °C – 29 °C)
Relative Humidity Range: 10 – 85%
Inert Gas Source
The Liberty Blue requires an inert gas source (either high purity grade nitrogen or argon) capable of supplying 25
psi (20 L/min ow) within ten feet (10’)/three meters (3 m) of the right side of the instrument.
Electrical Requirements
The Liberty Blue requires electrical power of 120 VAC (60 Hz, 1.7 A) (or 240 VAC [50 Hz, 1.7 A] where applicable).
Specic power requirements (120 VAC vs. 240 VAC) can be found on the nameplate afxed to the rear of the
Liberty module and on the side of the Discover module.
Three (3) grounded electrical connections providing a total of 10 A are required for all components:
Liberty Blue power cord
Router power cord
Controller (laptop computer) power cord
Fuse Replacement
The Liberty Blue has four operator replaceable fuses located in the power inlet module (at the rear of the
instrument, where the power cord connects to the Liberty Blue module). The fuses are rated F 250 V 2 A. The
top pair of fuses (PN BR198826) are North American style, 5 mm x 20 mm size, and are rated F 250 V 2 A. The
bottom pair of fuses (PN 188340) are North American style, 5 mm x 20 mm size, and are rated F 250 V 10 A.
NOTE
Optionally, the router can be powered directly from the Liberty Blue module without the need for an
external connection (using Router-Serial Power Cable, PN 243290).
