CET PMC-53A User Manual

CET Electric Technology
32
Group #9
Type
Setpoint Type
0=Disabled, 1=Over Setpoint
2=Under Setpoint
0
Parameter
1
Setpoint Source
See Table 3-11
None
OvLim
Over Limit
0
UnLim
Under Limit
0
ActiveDelay
Active Delay
0 to 9999s
0
InactiveDelay
Inactive Delay
0 to 9999s
10
Trigger1
2
Setpoint Trigger1
See Table 3-12
10
Trigger2
2
Setpoint Trigger2
See Table 3-12
I/O
Digital Input
3
Function
3
DI Function
DI1
Function Mode for DI1 to DI6
Digital Input /
Pulse Counter /
Tariff Switch
4
Digital
Input
…
DI6
Debounce
3
Specifies the minimum duration the DI must remain in the Active or Inactive
state before a state change is considered to be valid.
DI1
Debounce for DI1 to DI6
1 to 9999 ms
20 ms
…
DI6
Pulse Weight
3
Specifies the incremental value for each pulse received
DI1
Pulse Weight for DI1 to DI6
1 to 1000000
1
…
DI6
Digital Output
3
Pulse Width
3
Specifies the duration for which the relay output will be active when a remote
control command is received to activate it.
DO1
Pulse Width for DO1 to DO4
0 to 600 (x0.1s)
(0=Latch Mode)
10
DO2
DO3
DO4
Function
3
Specifies the function of the Digital Output.
DO1
#
DO Control Mode
 Remote Control / Alarm
 kWh Import
 kWh Export
 kWh Total
 kvarh Import
 kvarh Export
 kvarh Total
Remote
Control/
Alarm
DO2
#
DO3
DO4
RTD
3
RTD1 Compensation
RTD Compensation
5
0 to 2000 (x0.01Ω)
0.00Ω
RTD2 Compensation
Analog Input
3
Type
Select between
0-20mA or 4-20mA input
4-20mA / 0-20 mA
4-20mA
Zero Scale
The value that corresponds to
the minimum Analog Input of
0 or 4 mA
-999,999 to 999,999
400
Full Scale
The value that corresponds to
the maximum Analog Input of
20 mA
-999,999 to 999,999
2000
Analog Output
3
Type
Select between
0-20mA or 4-20mA output
4-20mA / 0-20mA
4-20mA
Key
6
The parameter to which the
Analog Output is proportional
See Table 3-13
Uab
Zero Scale
The parameter value that
corresponds to the minimum
Analog Output of 0 mA or 4
mA
-999,999 to 999,999
0
Full scale
The parameter value that
corresponds to the maximum
Analog Output of 20 mA
-999,999 to 999,999
0
Display
Timeout
Backlight Timeout
0 to 60 min
5
Contrast
Display Contrast
0 to 9
5
