CET PMC-53A User Manual

CET Electric Technology
33
Language
System Language
Chinese/English
English
Delimiter
7
Delimiter
Option1/Option2
Option1
Main 1st*
Default Display 1
st
parameter
See Note 8)
Ullavg
Main 2nd*
Default Display 2
nd
parameter
Iavg
Main 3rd*
Default Display 3
rd
parameter
P (kW Total)
Main 4th*
Default Display 4
th
parameter
PF (Total)
SP LCD Alarm~
9
Enable Flashing LCD Alarm
On/Off
On
Clock
Time
Time
(20)YY-MM-DD
/
Date
Date
HH:MM:SS
/
Date Format
Date Format
YYMMDD/
MMDDYY/
DDMMYY
YYMMDD
Maintenance
Password Setup
New Password
Enter new password
Confirm Password
Confirm new password
Clear Registers
Energy
Present
10
Clear Present Energy
Measurements and Energy Log
Yes/No
No
History
11
Clear Historical Monthly
Energy Log
Yes/No
No
Demand
Present Max
Clear Peak Demand Log of This
Month (Since Last Reset)
Yes/No
No
All
Clear Present Demand, Peak
Demand Log of This Month
(Since Last Reset) and Last
Month (Before Last Reset)
Yes/No
No
Max./Min.
Present
Clear Max./Min. Log of This
Month (Since Last Reset)
Yes/No
No
All
Clear Max./Min. Log of This
Month (Since Last Reset) and
Last Month (Before Last Reset)
Yes/No
No
Operating Time
Reset
Clear Device Operating Time
Yes/No
No
Pulse Counter
All
Clear All DI Counters
Yes/No
No
DI1
Clear
DIx Pulse Counter
Yes/No
No
…
DI6
SOE Logs*
Clear SOE Logs
Yes/No
No
Clear All Data
-
Clear All of the above
Yes/No
No
DO Control
DO1
DOx Manual Control
Normal/On/Off
Normal
DO2
DO3
DO4
Information
Check meter information
Firmware
Firmware Version
e.g. V1.00.01
Update
Date of the latest firmware
update
e.g.20160701
Modbus
Modbus Protocol Version
e.g. V1.4
BACnet MSTP*
BACnet MSTP Protocol Version
e.g. V1.7
N2*
N2 Protocol Version
e.g. V1.0
DNP~
DNP Protocol Version
e.g. V1.0
SN
Serial Number
e.g. 1506005094
* Available in Firmware V1.00.03 or later
#
Available in Firmware V1.00.04 or later
~ Available in Firmware V1.00.06 or later
Table 3-10 Setup Parameters
Notes:
1) The table below illustrates the Setpoint Parameters.
