CET Electric Technology
34
Key
Setpoint Parameter
Scale
Unit
0
None
-
-
1
Uln (Any Phase Voltage)
x1
V
2
Ull (Any Line Voltage)
3
I (Any Phase Current)
A
4
In (Calculated)
5
Frequency
Hz
6
P (kW Total)
W
7
Q (kvar Total)
var
8
S (kVA Total)
VA
9
PF (PF Total)
-
10
P DMD (kW Total Present Demand)
W
11
Q DMD (kvar Total Present Demand)
var
12
S DMD (kVA Total Present Demand)
VA
13
P DMD Pred (kW Total Predicted Demand)
W
14
Q DMD Pred (kvar Total Predicted Demand)
var
15
S DMD Pred (kVA Total Predicted Demand)
VA
16
U THD
100%
17
U TOHD
100%
18
U TEHD
100%
19
I THD
100%
20
I TOHD
100%
21
I TEHD
100%
22
U Unbal (Voltage Unbalance)
100%
23
I Unbal (Current Unbalance)
100%
24
Reversal (Phase Reversal)
3
-
25
I4 (Measured)*
x1
A
26
AI*
-
27
Reserved
-
-
28
RTD1*
x1
°C
29
RTD2*
30
Ir (Residual Current)~
x1
A
31
U2 (-ve Sequence Unbalance)~
x1
V
32
U0 (Zero Sequence Unbalance)~
* Appears only if the device is equipped with the appropriate option
~ Available in Firmware V1.00.06 or later
Table 3-11 Setpoint Parameters
2) The table below illustrates the options for Setpoint Trigger.
Key
Action
Key
Action
0
None
3
DO3 Closed
1
DO1 Closed
4
DO4 Closed
2
DO2 Closed
Others
Reserved
Table 3-12 Setpoint Trigger
3) This menu only appears if the meter is equipped with the corresponding options.
4) Tariff Switching is available in Firmware V1.00.03 or later and only valid for DI1 to DI3.
5) Please refer to Chapter 4.1.6 for a detailed description of RTD Compensation.
6) Analog Output Parameters
If PF Total or Freq is chosen as the AO parameter, the values for ZERO (zero scale) and FULL (full
scale) should be set as 1000 or 100 times the actual value, respectively. The Units for Voltage,
Current, kW, kvar, kVA and FREQ are V, A, kW, kvar, kVA and Hz, respectively.
Key
Parameter
Scale
Unit
Key
Parameter
Scale
Unit
0
Uab
x1
V
10
kVA Total
x1
kVA
1
Ubc
V
11
PF Total
x1000
-
2
Uca
V
12
Frequency
x100
-
3
Ull Average
V
13
kW Total Present Demand
x1
kW
4
Ia
A
14
kvar Total Present Demand
kvar
5
Ib
A
15
kVA Total Present Demand
kVA
6
Ic
A
16
Uan
x1
V
7
I Average
A
17
Ubn
V
8
kW Total
x1
kW
18
Ucn
V
9
kvar Total
kvar
19
Uln Average
V
Table 3-13 Analog Output Parameters
