CET PMC-53A User Manual

CET Electric Technology
65
SOE Classification
Event
Classification
Sub-
Classification
Status
Event Value
Description
1=DI Changes
1
1 / 0
DI1 Inactive / DI1 Active
2
1 / 0
DI2 Inactive / DI2 Active
3
1 / 0
DI3 Inactive / DI3 Active
4
1 / 0
DI4 Inactive / DI4 Active
5
1 / 0
DI5 Inactive / DI5 Active
6
1 / 0
DI6 Inactive / DI6 Active
2=DO Changes
1
1 / 0
DO1 Operated/Released
by Remote Control
2
1 / 0
DO2 Operated/Released
by Remote Control
3
1 / 0
DO3 Operated/Released
by Remote Control
4
1 / 0
DO4 Operated/Released
by Remote Control
5~10
Reserved
11
1 / 0
DO1 Operated/Released by Setpoint
12
1 / 0
DO2 Operated/Released by Setpoint
13
1 / 0
DO3 Operated/Released by Setpoint
14
1 / 0
DO4 Operated/Released by Setpoint
15~20
Reserved
21
1 / 0
DO1 Operated/Released by Front Panel
22
1 / 0
DO2 Operated/Released by Front Panel
23
1 / 0
DO3 Operated/Released by Front Panel
24
1 / 0
DO4 Operated/Released by Front Panel
25~30
Reserved
31
0
DO1 Released when Pulse Time out
32
0
DO2 Released when Pulse Time out
33
0
DO3 Released when Pulse Time out
34
0
DO4 Released when Pulse Time out
3=Setpoint
1
1 / 0
Trigger
Value /
Return
Value
Over Uln Setpoint Active/Return
2
1 / 0
Over Ull Setpoint Active/Return
3
1 / 0
Over Current Setpoint Active/Return
4
1 / 0
Over In Setpoint Active/Return
5
1 / 0
Over Frequency Setpoint Active/Return
6
1 / 0
Over kW Total Setpoint Active/Return
7
1 / 0
Over kvar Total Setpoint Active/Return
8
1 / 0
Over kVA Total Setpoint Active/Return
9
1 / 0
Over PF Total Setpoint Active/Return
10
1 / 0
Over kW Total Present Demand Setpoint
Active/Return
11
1 / 0
Over kvar Total Present Demand
Setpoint Active/Return
12
1 / 0
Over kVA Total Present Demand Setpoint
Active/Return
13
1 / 0
Over kW Total Predicted Demand
Setpoint Active/Return
14
1 / 0
Over kvar Total Predicted Demand
Setpoint Active/Return
15
1 / 0
Over kVA Total Predicted Demand
Setpoint Active/Return
16
1 / 0
Over Voltage THD Setpoint Active/Return
17
1 / 0
Over Voltage TOHD Setpoint
Active/Return
18
1 / 0
Over Voltage TEHD Setpoint
Active/Return
19
1 / 0
Over Current THD Setpoint
Active/Return
20
1 / 0
Over Current TOHD Setpoint
Active/Return
21
1 / 0
Over Current TEHD Setpoint
Active/Return
22
1 / 0
Over Voltage Unbalance Setpoint
Active/Return
