CET PMC-53A User Manual

CET Electric Technology
66
23
1 / 0
Over Current Unbalance Setpoint
Active/Return
24
1 / 0
Reversal Phase Setpoint Active/Return
25
1 / 0
Over I4 Setpoint Active/Return
26
1 / 0
Over AI Setpoint Active/Return
27
Reserved
28
1 / 0
Over Temprature1 Setpoint
Active/Return
29
1 / 0
Over Temprature2 Setpoint
Active/Return
30
1 / 0
RTD 1 Broken
31
1 / 0
RTD 2 Broken
32
1 / 0
Over Ir (Residual Current) Setpoint*
Active/Return
33
1 / 0
Over U2 (Negative Sequence) Setpoint*
Active/Return
34
1 / 0
Over U0 (Zero Sequence) Setpoint*
Active/Return
35~40
Reserved
41
1 / 0
Under Uln Setpoint Active/Return
42
1 / 0
Under Ull Setpoint Active/Return
43
1 / 0
Under Current Setpoint Active/Return
44
1 / 0
Under In Setpoint Active/Return
45
1 / 0
Under Frequency Setpoint Active/Return
46
1 / 0
Under kW Total Setpoint Active/Return
47
1 / 0
Under kvar Total Setpoint Active/Return
48
1 / 0
Under kVA Total Setpoint Active/Return
49
1 / 0
Under PF Total Setpoint Active/Return
50
1 / 0
Under kW Total Present Demand
Setpoint Active/Return
51
1 / 0
Under kvar Total Present Demand
Setpoint Active/Return
52
1 / 0
Under kVA Total Present Demand
Setpoint Active/Return
53
1 / 0
Under kW Total Predicted Demand
Setpoint Active/Return
54
1 / 0
Under kvar Total Predicted Demand
Setpoint Active/Return
55
1 / 0
Under kVA Total Predicted Demand
Setpoint Active/Return
56
1 / 0
Under Voltage THD Setpoint
Active/Return
57
1 / 0
Under Voltage TOHD Setpoint
Active/Return
58
1 / 0
Under Voltage TEHD Setpoint
Active/Return
59
1 / 0
Under Current THD Setpoint
Active/Return
60
1 / 0
Under Current TOHD Setpoint
Active/Return
61
1 / 0
Under Current TEHD Setpoint
Active/Return
62
1 / 0
Under Voltage Unbalance Setpoint
Active/Return
63
1 / 0
Under Current Unbalance Setpoint
Active/Return
64
1 / 0
Under I4 Setpoint Active/Return
65
1 / 0
Under AI Setpoint Active/Return
66
Reserved
67
1 / 0
Under Temprature1 Setpoint
Active/Return
68
1 / 0
Under Temprature2 Setpoint
Active/Return
69
1 / 0
Under Ir (Residual Current) Setpoint*
Active/Return
70
1 / 0
Under U2 (Negative Sequence) Setpoint*
Active/Return
