CET PMC-53A User Manual

CET Electric Technology
88
AV 9615
Clear DI #6 Counter
W
65280
#
PT Ratio × CT Ratio × Rated Phase Voltage Input × Rated Current Input x √3 must be less than 790,000,000.
5) Binary Input Objects (PMC-53A’s Digital Inputs)
Optional Properties Supported: Description, Reliability
Use the Present_Value properties of the Binary_Input objects as alerts for conditions of potential
concern regarding system measurements. These objects support the Description and Reliability
optional properties and all required Binary_Input object properties. None of them are writable.
Register
Description
Property
Note
BI0
DI 1
R
0 = Inactive, 1 = Active
BI1
DI 2
R
0 = Inactive, 1 = Active
BI2
DI 3
R
0 = Inactive, 1 = Active
BI3
DI 4
R
0 = Inactive, 1 = Active
BI4
DI 5
R
0 = Inactive, 1 = Active
BI5
DI 6
R
0 = Inactive, 1 = Active
6) Binary Output Objects (PMC-53A’s Digital Outputs)
Optional Properties Supported: Inactive_Text, Active_Text
Use the Present_Value property of the Binary_Output objects as alerts for DO conditions.
Reading Binary_Output objects have the highest priority. PMC-53A supports Inactive_Text,
Active_Text optional properties and all required Binary_Output object properties. Present_Value,
Out_Of_Service and Polarity properties can be written, but these are non-volatile after
modification. The Present_Value can only be written when the Out_Of_Service is true to change
the state of the Digital Output and will be written as W when the Out_Of_Service is false.
Register
Description
Property
Note
BO0
DO 1
R/W
0 = Inactive, 1 = Active
BO1
DO 2
R/W
0 = Inactive, 1 = Active
BO2
DO 3
R/W
0 = Inactive, 1 = Active
BO3
DO 4
R/W
0 = Inactive, 1 = Active
7) Additional Front Panel Setup Parameters for BACnet MS/TP
The following BACnet MS/TP setup parameters should be configured via the PMC-53A’s Front
Panel before connecting the PMC-53A to a BACnet MS/TP network.
Parameters
Description
Option/Range
Default
MAC
MS/TP ID
^
0 to127
100
INST
Object Identifier
#
0 to 4194302
26001
MAXMAS
Maximum Number of Master
0 to 127
127
LOCK
Disable communication
YES/NO
NO
BAUD
Baud rate
1200/2400/4800/9600/19200/38400
9600
CONFIG
Comm. Port Configuration
8N1/8E1/8O1/8N2/8E2/8O2
8E1
^
The MS/TP ID is similar to the Modbus unit ID conceptually
#
The Object Identifier is similar to the IP address of an Ethernet network conceptually and is required to be
unique within the entire BACnet network
