ChemoformGroup CF Control 100 - Installation Drawing Closed Sample Water System

CF Control Installation
07/2017
Page
11
3.3 Installation drawing "Closed sample water system"
Fig. 3-1
Dosing line
-
disinfection 6/4
mm PTFE
(white)
Dosing line
- pH reduce 6/4 mm PE
(yellow)
Supply container
dinochlorine liquid
Supply unit dinominus
liquid
From pool
Dosing pump for dosing of
pH plus (optionally)
Schuko socket
interlocked
with
filter pump
Mains connection
Filter control
Water sampling point
Sample water return
Open drain
connection
To pool
Ball valve
Injection valve chlorine
Injection valve pH reduce
Injection valve pH raise
Flow monitor
Heating circulation pump
Heating flow
Heating return
Heat

exchanger
NOTE:
Please observe the information given in the section water sampling!
Suction lance
Supply unit
dinoplus liquid
(optional)
Suction lance
Filter system
Backwash line
