Operating instructions
CF Control 100
10.2 Commissioning
Please proceed in the following sequence for commissioning the system:
1) Set the time (chapter 9.1)
2) Set the filter times switching marks (chapter 9.2)
3) In case of solar heating: change to solar and set up (chapter 8)
4) Calibrate the pH electrode (chapter 7.1)
5) Set the disinfectant content (chapter 7.3)
6) Adjust the set points for pH, chlorine and water temperature (chapters 6.2 and
8.2)
10.3 Activating the complete system
Once you have ensured that all instructions up to this point have been observed and
that the CF Control 100 is correctly set and calibrated, you can switch on the dosing
pumps: As soon as the water values deviate from the settings, the pumps start
dosing (after elapse of the switch-on delay).
The button is used to the control of chlorine/pH on or off.
Diode "Dosing on" lights = Control ON
Diode "Dosing on" off = Control OFF
10.3.1 Control limits
The dosing for Rx and pH is only released when the measured values are within
specific limits. If this is not the case, a malfunction of the probe or measuring input is
assumed and no dosing is carried out.
If one of the values is outside the limits, the display of the particular value starts
flashing.
Limits: Redox: 50 - 950mV
pH: 3 – 12
Note: If the actual value is outside the limits during commissioning, this value must
be adjusted first by a manual addition of chemicals until it is within the required
