Operating instructions
CF Control 100
Press to return to the display level.
8.6 Activation of the solar heating [parameter 94]
The solar heating is connected by the CF Control 100 when the following conditions
are fulfilled:
1. The heating is changed to solar heating
2. The set switch-on delay has elapsed.
3. Sample water is circulating.
4. The filter pump is switched on.
5. The actual temperature of the pool water is below the adjusted set point
temperature for one minute.
6. The temperature at the solar absorber is higher than a temperature specified
by you for one minute.
The purpose of point 6 is to ensure that the solar energy is sufficient to supply the
required heat energy.
We assume in our example that the solar heating is to be activated when the
temperature at the solar absorber is 16 °C above the pool water temperature.
In this case, enter this difference (16°C) as value for parameter .
Press the Eingabe / ENTER button and choose parameter P 95 (confirm with
).
Then set the difference value that you have determined.
Eingabe / ENTER
Press to return to the display level.
When the temperature at the solar absorber permanently goes down for 2°C below
this switch-on temperature, the solar heating is switched off again. (This is also the
case if one of the other pre-conditions described before is not fulfilled any longer).
