CF Control 100 Technical data
07/2017
Page
49
14 Technical data
15
14.1 General
14.1.1 General settings
Power supply 230 V/AC ± 10 % (50/60 Hz) or
115 V/AC ± 10 % (50/60 Hz)
switching is automatic
Power consumption
10 VA
Protection class:
IP 65
Fuse (device)
250 V / 80mA T
Contact load, relay
max. 500 W, max. 250 V
Working t
emperature
0 to + 50° C
Permissible storage temperature
-
20 to +65
-
c
Permissible humidity
max. 90% at 40°C (non
-
condensing)
Length of power cord
1.6 meter
Dimensions device
215 x 185 x 100 mm (w x h x d)
Dimensions mounting plate
600 x 360 x 8 mm (w x
h x d)
Tonnage
1.8 kg
Switch
-
on delay
0
-
30min
Alarm output (only when operated as
measuring and control instrument)
Normally closed contact (NCC) or normally
open contact (NOC) (switchable)
14.1.2 Settings chlorine control
Control characteristics
pH contr
oller
Control response On-Off or pulse frequency or pulse interval
(adjustable)
Pulse frequency, if adjusted
1
-
7200 pulses/min. (adjustable in pulses)
Pulse duration in case of pulse
frequency
250 ms constant
Minimum pulse in case of pulse
interval,
if adjusted
0.5 – 10 sec. (adjustable in steps of 0.1 sec
Period in case of pulse interval, if
adjusted
10 – 60 sec. (adjustable in sec.)
Permanent
dosing time monitoring
0
–
90 min. (adjustable in min.)
Permanent monitoring of dosing
quantity
0 – 30 liters/day (adjustable in steps of 0.1
liter)
Dosing capacity 0.5 – 8 liters / hour (adjustable in steps of
0.1 liter)
15
For information and data about dosing quantities, counter pressures etc., refer to the manual of the
dosage pumps installed in your system please.
