CF Control 100 Electrical connection
07/2017
Page
23
4.3 Connections of filter pump
If the CF Control 100 is intended to drive a filter pump, it is switched via relay 4
(terminal 12-13). The maximum capacity of the filter pump must be 0.5 kW at 230 V.
4.4 Connection heating / solar heating
7
The CF Control 100 can drive a heating or a solar heating system. When there is a
demand for heating, a potential-free two-way contact is switched. Connections:
terminals 8 and 9, terminal 10 is used for the phase coming from the wire connector
box. This can be used to connect a heating pump (cl. 9), a motorised ball valve or a
3-way solenoid valve (terminal 8 „Open“, terminal 9 „Closed“). The maximum
capacity of the heating pump must be 0.5 kW at 230 V.
7
The solar temperature sensor is not included.
Note:
When using 400 V pumps, an additional three-phase contactor with motor
protection and the following ampere scale is required:
1.0 - 1.6 A, 400 V Art. no.: 0960-277-00
1.6 - 2.4 A, 400 V Art. no.: 0960-278-00
2.4 - 4.0 A, 400 V Art. no.: 0960-279-00
4.0 - 6.0 A, 400 V Art. no.: 0960-280-00
6.0
-
9.0 A, 400 V Art. no.: 0960
-
281
-
00
