Operating instructions CF Control 100
Page
22
02/2017
14
+24V
Not assigned
15
Pulse
Sample water deficiency, potential-free,
normally open contact
16
GND
17
BIN0
Empty signal input chlorine, potential-free,
normally open contact
18
BIN0
19
BIN1
Empty signal input pH correction chemicals, potential-
free, normally open contact
20
BIN1
21
Leakage detection from dosing pumps,
normally open contact, not assigned
22
23
Connection water temperature sensor PT1000
24
25
Connection solar temperature sensor PT1000
26
27
+
Measuring input redox
28
-
29
+
Measuring input pH
30
-
Explanations:
- NC: Normally Closed, output works as normally closed contact
- NO: Normally Opened, output works as normally open contact
- COM: Common, shared connection
- From wire connector box N, L , PE: There are three 5-pole wire connector
boxes connected in the unit for power distribution
(see diagram, chapter 19)
Note: The plugs can be removed for an easier installation of the connection
cables outside the terminal box.
Note: A resistor is installed at the works for terminal 23-24 (water temperature
sensor). When connecting the Pt1000, this resistor mus
t be removed.
