ECO 2 Ultrasound Diagnostic System
Page 99 / 189
Caption
Display the name of selected term that is display names in
the measurement menu
Var Name
The name of built-in selected measurement menu, user
don’t need modify while display order according to the
names
Unique Name
Built-in code, user don’t need modify
Tool Type/Tool
Select available measurement tool type
B distance (B line),area/circumference(ellipse, trace), M
distance(M vertical line), time(M horizontal line), M
slope(M slant)
Name
Needed measurement operation of specific measurement
and calculation
Unit
Data unit which measurement operation produces
Display In Report
Whether display in the report or not.
Up
Press this button to move measurement operation up
Down
Press this button to move measurement operation down
Average Method
The average rule of data
Add
Press this button to pop up interface to add measurement
operation
Modify
Press this button to pop up interface to modify
measurement operation
Remove
Press this button to delete selected measurement
operation
7.2.2.4 Create Measurement Operation
Press [Add] in measurement operation interface, pop up the following dialog box.
