ECO 2 Ultrasound Diagnostic System
Page 31 / 189
system and the probe.
CAUTION:
Before connecting the probe, please carefully check the probe lens, probe cable and probe
connector to see whether there is anything abnormal, such as cracks, falls off. Abnormal probe is
not allowed to connect to the system; otherwise there is possibility of electricity shock.
Hold the probe connector lock switch, and insert the connector socket vertically.
Release the probe lock switch.
Check the locked probe with one hand to make sure that it’s not loose, and it’s securely
connected
CAUTION:
Only power supply at “turn off” state, can install / take-down the probe, otherwise it will damage
the machine or the probe.
When installing and disassembling probe, please put the probe head inside the probe holder, it
can prevent the probe falling down to the ground.
3.5.3.1 Probe Disassembly
Turn the dead lock switch 90degree in counterclockwise direction, extract probe connector plug
vertically.
3.5.4 Accessories Installation
CAUTION: Please only use the optional parts provided or suggested by manufacturer!
Using other types of optional devices may cause the damage to the system and the connected
optional devices.
3.5.4.1 Video printer installation
1. Put video printer stably.
2. Connect cable of video printer to video port in the back of the device. And connect the other
side to video signal output port in the rear side.
3. Connect the printer line to print control port in the printer rear side, and connect the other side
to the print control port in the unit rear side.
4. Connect power cable of video printer to power system.
