ECO 2 Ultrasound Diagnostic System
Page 48 / 189
to change Focus Position.
5.6.12 ANGLE/ZOOM
Press [ANGLE/ZOOM] button until the indicator of [ANGLE] is lit, and the angle of sample gate will
rotate with the rotation direction. Change the angle of sampling line of sampling gate in PW mode.
Press [ANGLE/ZOOM] button to confirm the ZOOM button is lit, and it will appear the zoom box,
rotate the button to select the zoom steps.
5.6.13 INVERT
B mode image and B/M mode image can be reversed horizontally and vertically.
Press the key, the displayed image is reversed in the right-left horizontal direction.
Press the key, the displayed image is reversed in the up-down vertical direction.
The horizontal flip status indicators of the upper-left corner of the image window have the following
meanings:
The meaning of the symbol “ ” indicating the probe initiative scanning position “ ” situated in the
left indicates that the first scanning line in the left of the screen is corresponding to the initiative
scanning position of the probe,
“ ” situated in the right indicates that the first scanning line in the right of the screen is
corresponding to the initiative scanning position of the probe.
5.6.14 THI
Turn ON/OFF THI.
5.6.15 AIO
Press this key to optimize image.
5.7 B Image Menu Adjustment
Click [Change] button or [MENU] button to display the menu.
Rotate [MENU] button or press [Cursor] button to display the cursor ,and move the sample box to
the corresponding function, press [MENU] button to update the function, then rotate [MENU]
button to adjust the function, press [MENU] again to exit the function.
5.7.1 Scan Width
Select [Scan Width], and adjust the scan width to the corresponding size.
To Next Page
