Chore-Time Chore-Tronics 3 Control User Manual

Control Installation Chore-Tronics® 3 Control
106
MT2398C
Bird Scale Wiring using the LCC Board (Scales More than 150’ from Control)
Insert a Small Screw Driver
CT3 I/O Board
SJB
Twisted Pair
-
Scale 1 Scale 2
Load Cell
ON
123 4 52
-
+
-
+
24 vdc supply from CT3 can be used if using a 32 output Con- trol. Order part #43288, 24V DC Power Supply Assembly if
more than 32 outputs.
-
++
Shield Black Blue Brown Red
Green
White
-
-
-
+
+
-
-
ON
123 4 52
Address Settings
Dip Switch
Address # 12345
3 XX - - - 4 --X-- 5 X-X- - 6 -XX- - 7 XXX - - 8 ---X- 9 X- -X-
10 -X-X-
11 XX - X -
12 --XX- 13 X-XX- 14 -XXX- 15 XXXX -
"X" is Dip switch in the On position
and press while inserting
Wires to lock in place
Non Shielded Wire
24 vdc supply from CT3 can be used if using a 32 output Con- trol. Order part #43288, 24V DC Power Supply Assembly if
more than 32 outputs.
Address one number higher than last one used on Scale 1.
Address is one number higher than the highest number switchboard
