Item Description Part No. Item Description Part No.
1 Electric Box 14 x 16 42684 28 Temperature Sensor 40741
2 275V MOV 14063-1 29 Liquid Tight Connector 3/8" (Not Shown) 13477
3 I/O Board (CT3 replacement) 53332-485 30 Liquid Tight Connector 1/2" (Not Shown) 23779
4 Power Supply 49649 31 Conduit Locking Nut (Not Shown) 3357
5 Static Pressure Harness 53292 32 Caution Decal 2527-51
6 Incoming Power Cable 53333 33 Terminal Strip 3-Pole 1.24" 34925-3
7 Ribbon Cable Clamp 50130 34 Input Power Decal 2526-428
8 Carrier Board (CBM) 51845 35 LED Cable (For Repair) 53328
9 Static Pressure Sensor 44743 36 Touch Screen Mounting Bracket 52585
10 Grounding Rail 43384-2 37 Power Cable 53293
11 Display 53754 38 IO to CBM Cable 51857
12 SBC Board 53755 39 24V DC Coil Relay 42509
13 4-40 Hex Nut 3511 40 3 Position Terminal Strip 26862
14 Nylon Spacer (KD Board) 43382 41 Display W/TCON (For Repair) 51847-1
15 TCON Board (Timer Control) 51849 42 Plate CT 3 CBM Mounting 54131
16 CT3 LVDS Cable (For Repair) 54193 43 CT 3 RS 485 CBM Converter Board 54293
17 Back Light Cable (For Repair) 51851 44 Cable 24 in. Ethernet 54364
18 Electric Box Lid 14" x 16" 42683 45 CT3 RS 485 IOM Converter Board 54294
19 Control Box Latch 30862 46 Bottom Plate 52601
20 Latch Pivot 30863 47 Cover Plate 51856
21 USB External Port 51852 48 Input Cover Plate Decal 2526-538
22 USB External Port Cap 51873 49 Front Plate 51855
23 Main Decal 2529-915 50 Foam Tape (3.25’) 48425
24 Caution Decal 2527-62 51 Aluminum Hinge 49482
25 .05" Spacer 43381 52 .125 Neoprene Seal (4.76’) 34767
26 Ground Symbol Decal 2527-63 53 .5 x .36 Weatherstripping 50029
27 USB Cable 51853
