Parts Listing (Relay Box)

Item Description Part No. Item Description Part No.

1 Electric Box 15 x 22 51466 16 Decal, Relay assigned to 2526-505

2 Electric Box Lid 51467 17 Hole Placement Decal 2527-72

3 Control Box Latch 30862 18 Ribbon Cable Clamp 50130

4 Latch Pivot 30863 19 56 Relay Cable 52536

5 Relay Board (RM4) 51861 40/48 Relay Cable 53505

6 Relay Board (IMSCM16) 49673 32 Relay Cable 53504

7 Relay Board (IMSCM8) 49672 20 Switch Sticker Decal 2529-684

8 Flat Cable 10P-380mm 49738 21 Ground Wire (17") (Not Shown) 52560

9 Flat Cable 10P-51mm 52535 22 Ground Wire (11") (Not Shown) 52561

10 CT3 Relay Box Decal 2529-916 23 Top Plate 51858

11 Grounding Rail 3.15" 43384-2 24 Relay Mount 52534

12 Caution Decal 2527-62 25 Aluminum Hinge 49482

13 Ground Decal 2527-63 26 .125 Neoprene Seal (6.5’) 34767

14 Terminal Strip (4 Pole) 34925-4 27 Cover Plate 52716

15 Terminal Strip Decal 2526-439

Chore-Tronics® 3 Control Parts Listing (Relay Box)

MT2398C

137
