6. Name Clock- Is the current displayed
clock.
7. Events- The current number of events that
the Clock is using to control the lignts.
8. Use Curve- selecting On or Off from the
dropdown activates or deactivates the
curve selected. If the light clock curve is
set to ON, then the current light clock set-
tings will not be editable. To temporarily
change the current light clock settings,
first set the curve to OFF, then make the
desired changes. To return to the curve set-
tings, change the curve back to ON.
678
Light Clock Curve Set "ON"
Light Clock Curve Set "OFF"
9. Time- Enter the time of day.
10. Relay: Turns the relay assigned to the
Light clock that the curve has been assigned
to on or off. This column will be blank if only
an Analog output is assigned.
