Chore-Tronics 2 Control User Manual

Chore-Tronics® 2 Control Improving Lightning Surge Suppression MT1843B
108
47660 FNET/ALARM & 47661 Telephone Line Surge Suppressor Wiring
ALARM
FNET
N
ALARM
FNET
ALARM
FNET
ALARM
FNET
OUT
IN
OUT
IN
OUT
IN
OUT
IN
Ground Wire Ground Wire Ground Wire Ground Wire
OUT
IN
IO
U
T
I/O Board I/O Board I/O Board I/O Board
Control
ControlControlControl
Interface
Box
Telephone
Dialer
Part No 47661
Telephone Line
Surge Suppressor
Ground Connection
From the Telephone
Company
Part No. 47660
FNET/ALARM
Surge Suppressor
Typical
3' Optimal Typ.
Figure 118. FNET Alarm and Telephone Line Surge Supressor Wiring
Note: There must be a ground rod within 10 ft. of the Ground Terminal of each
Surge Suppressor. The wire size from the Suppressor to the ground rod should
be 12 gauge or larger.
