Chore-Tronics® 2 Control Overview of Screens
MT1843B
31
(History-Production Screen) Auxiliary Digital Inputs History Tab
To access the History-Production "Auxiliary Digital Inputs screen", press the Tab
Key under "Dig. inp". This Screen will show the readings for all auxiliary digital
inputs for the last 13 days plus today. An auxiliary digital input can consist of Water
Meters not connected to the drinker lines (for example cool pad meter), pulsed
Output gas meters, pulsed Output electric meters, etc. Each auxiliary digital input can
have its own name to identify what kind of device is connected to the Input (Coolpad
Meter, Gas meter, etc.). The name(s) of the auxiliary digital inputs are entered in the
Setup-General: Digital Inputs Screen (Screen 13-Digital Inputs Tab). Only 1
auxiliary digital input is displayed at a time. To scroll to another Input, use the Index
Keys .
(History-Production Screen) Reset History Tab
To access the History-Production "Reset History" Screen, press the Tab Key under
"History". The Reset History-Production Screen is where the user can tell the Control
to erase all of the current production history data stored. Answer "Yes" or "No" to
"Are you sure to reset the history".
MT1842-068 10/04
1
Figure 31. History-Production Screen: Auxiliary Digital Inputs History Tab
MT1842-069 10/04
1
YES
Figure 32. History-Production Screen: Reset History Tab
MT1842-068 10/04
1
