Chroma 63600 Series User Manual

Programmable DC Electronic Load 63600 Series Operation & Programming Manual
4-24
MODE: CC
2. Set Load Level. There are 15,000 discrete steps from 0 to full scale in each range and
each mode. Turn the Rotary knob to change the display value to 10.000A, then press
key to confirm.
I_SET: 10.000 A
3. Set Slew Rate. Setting the rising and falling slew rate. Turn the Rotary knob to change
the display value, then press key to confirm.
: 0.0012A/μs
: 0.0012A/μs
4. Set Trigger Mode. There are three Trigger Modes and they are RISE , FALL and
HOLD_UP. Turn the Rotary knob to change the mode until the desired mode is
displayed on the VFD. Then, press key to select mode and confirm the setting.
TRG_M: FALL
5. Set Trigger Voltage. Trigger Voltage is the conduction voltage level.
TRG_S: It sets the start trigger voltage level for measurement time.
TRG_E: It sets the end trigger voltage level for measurement time.
The Electronic Load will measure the duration from the load on to the UUT output
voltage equal to the setting trigger voltage, and the Load stops sinking current when the
UUT output down to reach the voltage. Turn the Rotary knob to change the display
value, then press key to confirm.
TRG_S :3.000 V
TRG_E :5.000 V
6. Set the period of time out. The Electronic Load will measure the duration from the load
on to the UUT output voltage equal to the setting trigger voltage. When the time is
already over the period of time out, but the UUT output voltage still isn’t achieve to the
trigger voltage, the Load will load off and stop counting the timing. Turn the Rotary knob
to change the display value, then press key to confirm.
T_OUT: 600 s
ENTER
ENTER
ENTER
ENTER
ENTER

Chroma 63600 Series Specifications

General

Series	63600
Operating Temperature	0°C to 40°C
Modes	CC, CV
Interface	GPIB, USB
Protection	OCP, OTP, OVP
Voltage Resolution	1mV
Cooling	Forced Air
