Local Operation
Select Load module input status when it is powered ON. When ON is selected, the Load
module will be active using the last setting before turned OFF last time. The default setting of
AUTO_ON is OFF.
AUTO_ON : ON
Select LVP on/off. LVP is a default protection voltage set internally. When the Electronic
Load is under this voltage and in loading mode, it does not perform current loading until the
external voltage is larger than the LVP set protection voltage. The LVP default is OFF.
LVP : ON
Select ENTER status. It sets if skip to the next setting item or stay at its original setting
item when is pressed. The ENTER_KEY default is NEXT.
ENTER_KEY : NEXT
Trigger SHORT key. When is pressed, it enables SHORT mode if SHORT_KEY=
ENABLE. The SHORT_KEY default is ENABLE.
SHORT_KEY: ENABLE
Then the display will go to the first editing page again.
To leave out of the Setup page of system configuration, you need to press and
simultaneously to go back to the page of system configuration.
4.7.2 Setup of Specification
The Electronic Load allows the user to program specification of a UUT for later GO/NG
verification. During testing, it measures the UUT’s performance and compares it with the
spec. The Electronic Load allows the user to program spec for V, I, and Watt.
In the page of system configuration, turn the Rotary knob to change the display value to 2,
then press key into GO/NG SPEC page of system configuration.
Set the specifications of entry mode. The specifications of Load can be set by VALUE or
Percentage for HIGH and LOW data. The percentage values refer to the CENTER value of
specification. The default setting of SPEC entry mode is percentage.
MODE: PERCENT
Set Voltage specification. There are three levels for Voltage specification: CENTER, HIGH
and LOW. The CENTER level must be set by the value of channel input reference level. The
HIGH and LOW levels can be set by the value or percentage selected in configuration SPEC.
