Chroma 63600 Series User Manual

Programmable DC Electronic Load 63600 Series Operation & Programming Manual
2-2
Be sure that the following items listed by respective model are received completely.
Model No.
Item Name
Quantity
63600-1
Quick Start Guide - English
1 piece
User’s Manual CD
1 piece
Binding post fixer
1 piece
63600-2
Quick Start Guide - English
1 piece
Fuse 2A/250V, 5*20mm
1 piece
User’s Manual CD
1 piece
Binding post fixer
1 piece
63600-5
Quick Start Guide - English
1 piece
Fuse 5A/250V, 5*20mm
1 piece
User’s Manual CD
1 piece
Binding post fixer
1 piece
63601-5
Quick Start Guide - English
1 piece
User’s Manual CD
1 piece
Binding post fixer
1 piece
63610-80-20
White load wire (W33 00035), 75cm
2 pieces
Test wire red & black
2 pieces each
Y-type bare terminal, exradius ψ10.8mm
4 pieces
63630-80-60
63640-80-80
White load wire (W33 00033), 75cm
1 piece
Test wire red & black
1 piece each
Y-type bare terminal, exradius ψ13.8mm
2 pieces
63630-600-15
White load wire (W33 00033), 75cm
1 piece
Test wire red & black
1 piece
Y-type bare terminal, exradius ψ14mm
2 pieces
63640-150-60
White load wire (W33 00033), 75cm
1 piece
Test wire red & black
1 piece each
Y-type bare terminal, exradius ψ13.8mm
2 pieces
2.3 Explanation of Taking Apart
Please refer to Figure 2-1 when taking the instrument apart. Before using, please remove the
protective plate, and then plug the power cord so as to avoid short circuit. The sequences of
taking apart are as follows:
1. Three Screws on the bottom.
2. Four Screws on the two sides.
3. Protective plate

Chroma 63600 Series Specifications

General

Series	63600
Operating Temperature	0°C to 40°C
Modes	CC, CV
Interface	GPIB, USB
Protection	OCP, OTP, OVP
Voltage Resolution	1mV
Cooling	Forced Air
