Chroma 63600 Series User Manual

Local Operation
4-45
CV
H
80.000V
80.000V
80.000V
600.00V
150.00V
M
16.000V
16.000V
16.000V
150.00V
80.000V
L
6.0000V
6.0000V
6.0000V
80.000V
16.000V
CP
H
0000.4W
000.32W
0000.1W
000.00W
000.00W
M
000.04W
00.032W
000.01W
00.000W
00.000W
L
00.004W
0.0032W
00.001W
0.0000W
0.0000W
CZ(R
L
)
H
2900.0Ω
3000.0Ω
12000Ω
200.00kΩ
1500.0Ω
M
720.00Ω
600.00Ω
2900.0Ω
4000.0Ω
800.00Ω
L
020.00Ω
30.000Ω
080.00Ω
270.00Ω
60.000Ω
CZ
H
C
L
：000030μF Ls：00.0μH Rs：10.00Ω
M
L
Configuration list on panel: (Underline indicates factory default.)
Item1
Item2
Item3
Setting
CONFIGURE
1.SETUP
CC_VRANGE: HIGH
Von_POT: 000.00V
Von_LATCH: OFF
Vof_POT: 000.00V
CV_TYPE: VOLT_PSU
ALL_RUN: ON
EXT_WAVE: OFF
SIGN_OF_V: PLUS
WINDOW_T: 00.020s
SHORT_MOD: TOGGLE
SOUND: ON
AUTO_ON: OFF
LVP: ON
ENTER_KEY: NEXT
SHORT_KEY: ENABLE
2.GO/NG SPEC.
MODE: PERCERT
V_CENT: ------V
V_HIGH: ------%
V_LOW: ------%
I_CENT: ------mA
I_HIGH: ------%
I_LOW: ------%
P_CENT: ------W
P_HIGH: ------%
P_LOW: ------%
3.REMOTE
1.GPIB
ADDRESS: 07
2.SYSTEM BUS
ADDRESS: 01
TERMINATOR: ON
3.NETWORK
4.DIGITAL I/O
DOUT_1: NONE
DOUT_2: NONE
4.PARALLEL MODE
MODE: NONE
5.SYNC. DYNAMIC
MODE: NONE
6.CALIBRATION
PASWORD 0.0.0.0.0
7.DEFAULT
RECALL FACTORY
DEFAULT: YES

Chroma 63600 Series Specifications

General

Series	63600
Operating Temperature	0°C to 40°C
Modes	CC, CV
Interface	GPIB, USB
Protection	OCP, OTP, OVP
Voltage Resolution	1mV
Cooling	Forced Air
