Chroma 63600 Series User Manual

Programmable DC Electronic Load 63600 Series Operation & Programming Manual
5-88
Setting Syntax: STATus:CSUMmary:ENABle<space><NR1>
Setting Parameters: <NR1>, 0 ~ 1023, Unit = None
Bit Configuration of Channel Summary Register
Bit Position
9
8
7
6
5
4
3
2
1
0
Channel
10
9
8
7
6
5
4
3
2
1
Bit Weight
512
256
128
64
32
16
8
4
2
1
Setting Example: STAT:CSUM:ENAB 3
Query Syntax: STATus:CSUMmary:ENABle?
Return Parameters:<NR1>
Query Example: STAT:CSUM:ENAB? Return the setting of Channel
Summary Enable register.
Return Example: 3
STATus:CSUMmary:EVENt?
Type: Channel-Specific
Description: Indicate all channels of which an enabled STAT:CHAN Event
has occurred since last time the register was read.
Query Syntax: STATus:CSUMmary:EVENt?
Return Parameters:<NR1>
Query Example: STAT:CSUM:EVEN? Return the value of the Channel
Summary Event register.
Return Example: 3
STATus:QUEStionable:CONDition?
Type: Channel-Specific
Description: Real-time ("live") recording of Questionable data
Query Syntax: STATus:QUEStionable:CONDition?
Return Parameters:<NR1>
Query Example: STAT:QUES:COND? Return the channel status.
Return Example: 6
STATus:QUEStionable:ENABle
Type: Channel-Specific
Description: Mask to select which bit on the Event register is allowed to be
summed into the QUES bit for the Status Byte register.
Setting Syntax: STATus:QUEStionable:ENABle<space><NR1>
Setting Parameters:
Bit Configuration of Questionable Status Register
Bit Position
15~9
8
7
6
5
4
3
2
1
0
Condition
REMOTE INHIBIT
FAN
MAX LIM
SYNC
REV
OPP
OCP
OVP
OTP
Bit Weight
256 128 64 32 16 8 4 2 1
Setting Example: STAT:QUES:ENAB 24
Query Syntax: STATus:QUEStionable:ENABle?
Return Parameters:<NR1>, 0 ~ 65535, Unit = None
Query Example: STAT:QUES:ENAB Return the setting of the Status
Questionable Enable register.
Return Example: 24

Chroma 63600 Series Specifications

General

Series	63600
Operating Temperature	0°C to 40°C
Modes	CC, CV
Interface	GPIB, USB
Protection	OCP, OTP, OVP
Voltage Resolution	1mV
Cooling	Forced Air
