Chroma 63600 Series User Manual

Local Operation
4-11
otherwise, the new data won’t be written into the internal memory. At last, press
to exit the editing mode and complete the current range setting.
3. Select state A/B for single channel module
For single channel module, press the key to select state A or state B, then the
LED “A” or LED “B” above the key lights up. Select state A, by pressing the
key to select state A, then the LED “A” above the key lights up.
4. Set Resistance Level
There are 15,000 discrete steps from 0 to full scale in each range. Press the
key to enter into the editing mode. Turn the Rotary knob to change the display value to
2Ω, then press key to confirm.
2.000 Ω
The user may use or key to change the cursor position to different digit of
data, then turn the rotary knob to change the value of that digit.
If the user does not use or key to display the cursor, then resolution of the
value changes according to the rotary knob turning speed
5. Set the second Resistance Level for single channel module
Press the key to select State B then the LED “B” above the key lights
up.
Turn the Rotary knob to change the display value to 1Ω, then press key to
confirm.
1.000 Ω
6. Review and update the values of the setting parameters
Review the values of the setting parameters by pressing key. Update them by
set new value in their setting pages.
After completion of the data edit, key must be pressed. Otherwise, pressing the
key, new data will not be written into the internal memory, the previous value for
the parameter is kept.
7. Quit from editing mode
Press to quit from editing mode. Then, the VFD display will go back to the
voltage, current, and resistance display mode.
EDIT
A/B
A/B
A/B
A/B
EDIT
ENTER
A/B
A/B
ENTER
DATA
ENTER
DATA
EDIT
