AUDIO
TABLE OF CONTENTS
page page
AUDIO
DESCRIPTION ..........................1
OPERATION ............................1
DIAGNOSIS AND TESTING - AUDIO ..........1
ANTENNA BODY AND CABLE
DESCRIPTION ..........................4
OPERATION ............................4
DIAGNOSIS AND TESTING - ANTENNA BODY
AND CABLE ..........................4
REMOVAL .............................4
INSTALLATION ..........................5
ANTENNA MODULE - EXPORT
DESCRIPTION ..........................6
OPERATION ............................6
DIAGNOSIS AND TESTING - ANTENNA
MODULE - EXPORT ....................6
REMOVAL .............................7
INSTALLATION ..........................7
CD CHANGER
DESCRIPTION ..........................7
OPERATION ............................7
REMOVAL .............................7
INSTALLATION ..........................7
INSTRUMENT PANEL ANTENNA CABLE
REMOVAL .............................8
INSTALLATION ..........................8
QUARTER GLASS INTEGRAL ANTENNA -
EXPORT
DESCRIPTION ..........................8
OPERATION ............................8
DIAGNOSIS AND TESTING - QUARTER
GLASS INTEGRAL ANTENNA - EXPORT .....8
RADIO
DIAGNOSIS AND TESTING - RADIO ..........9
REMOVAL .............................9
INSTALLATION .........................10
RADIO NOISE SUPPRESSION COMPONENTS
DESCRIPTION .........................10
OPERATION ...........................10
REMOTE SWITCHES
DESCRIPTION .........................11
OPERATION ...........................11
DIAGNOSIS AND TESTING - REMOTE
SWITCHES ..........................11
REMOVAL .............................12
INSTALLATION .........................12
SPEAKER
DIAGNOSIS AND TESTING - SPEAKER ......12
REMOVAL .............................13
INSTALLATION .........................14
AUDIO
DESCRIPTION
There are four different system combinations avail-
able on this model. The available radio options are:
• AM/FM Cassette
• AM/FM Compact Disc with Compact Disc
changer controls
• AM/FM Cassette with single Compact Disc
Player and Compact Disc changer controls
• AM/FM Cassette with Compact Disc changer
controls
• AM/FM Cassette with Compact Disc player, rear
seat audio system and Compact Disc changer con-
trols.
The rear seat audio system allows passengers to
listen to a different music source, through head-
phones, other than what is playing through the vehi-
cles speaker system. A remote control is provided for
functions such as changing stations, tracks, disc and
modes while listening to rear seat audio. The radio
must be turned ON to use the rear seat audio sys-
tem.
All factory installed radio receivers are stereo Elec-
tronically Tuned Radios (ETR) and include and elec-
tronic digital clock function.
OPERATION
Operating instructions for the factory installed
audio systems can be found in the Owner’s Manual
provided with this vehicle.
DIAGNOSIS AND TESTING - AUDIO
Any diagnosis of the Audio system should
begin with the use of the DRB IIIt diagnostic
tool. For information on the use of the DRB
IIIt, refer to the appropriate Diagnostic Service
Manual.
Refer to the appropriate wiring information. The
wiring information includes wiring diagrams, proper
wire and connector repair procedures, details of wire
harness routing and retention, connector pin-out
RS AUDIO 8A-1
