139
CCD (SM1)
Preamble Decide whether to include the UPC-A/UPC-E/UPC-E1
preamble System Character (and Country Code) in the data
being transmitted.
No transmit: transmits none of the above
Transmit System Character: transmits system number only
Transmit Sys. Character and Country Code: transmits system
number and country code
Transmit
System
Character
Transmit Check Digit Decide whether to include the UPC-
A check digit (the last
character in the barcode) in the data being transmitted.
Enable
UPC-E
UPC-E Switch to enable UPC-E decoding. Enable
Addon 2 Decide whether to decode UPC-E with addon 2.
Ignore Addon
Auto-discriminate
Ignore addon
Addon 5 Decide whether to decode UPC-E with addon 5.
Ignore Addon
Auto-discriminate
Ignore addon
Preamble Decide whether to include the UPC-A/UPC-E/UPC-E1
preamble System Character (and Country Code) in the data
being transmitted.
No transmit: transmits none of the above
Transmit System Character: transmits system number only
Transmit Sys. Character and Country Code: transmits system
number and country code
Transmit
System
Character
Convert to UPC-A The UPC-E barcode will be expanded into UPC-A format, and
the next process will follow the settings configured for
UPC-A.
Disable
Transmit Check Digit Decide whether to include the UPC-E1
check digit (the last
character in the barcode) in the data being transmitted.
Enable
UPC-E1
UPC-E1 Switch to enable UPC-E1 decoding. Disable
Addon 2 Decide whether to decode UPC-E1 with addon 2.
Ignore Addon
Auto-discriminate
Ignore addon
Addon 5 Decide whether to decode UPC-E1 with addon 5.
Ignore Addon
Auto-discriminate
Ignore addon
