RS30 Mobile Computer Reference Manual
Code 128 0 Standard data packet. No Function Code 1“FNC1” in the first
character position.
1 Function Code 1“
” in the first character position.
2 Function Code 1“FNC1” in the second character position.
Interleaved 25 0 No check digit processing.
1 Check digit has been verified.
3 Check digit has been verified and stripped.
Codabar 0 No check digit processing.
Code 93 0 Always transmit 0.
MSI 0 Modulo 10 check digit verified and transmitted.
1 Modulo 10 check digit verified but not transmitted.
Industrial 25
(Discrete 25)
0 Always transmit 0.
UPC/EAN 0 Standard data packet in full EAN country code format, which
is 13 digits for UPC-A and UPC-E (not including addons).
3 Standard data packet with two-digit or five-digit addons.
4 EAN-8 data packet.
A UPC-A with Addon 2 barcode, 012345678905-10, is transmitted to the host
as a 18-character string,
001234567890510.
Bookland EAN 0 Always transmit 0.
Trioptic Code 39 0 Always transmit 0.
Code 11 0 Single check digit (has been verified.)
1 Two check digits (has been verified.)
3 Check digit has been verified but not transmitted.
GS1 DataBar (RSS) 0 Always transmit 0.
RSS-14 and RSS Limited will be transmitted with an Application Identifier “01”.
For example, an RSS-
14 barcode, 10012345678902, is transmitted
as
0110012345678902.
Note: In EAN-128 emulation mode, RSS is transmitted using Code 128 rules (= “]C1”).
EAN.UCC
Composites (RSS,
EAN-128, 2D
portion of UPC
composite)
Native mode transmission
0 Standard data packet
1 Data packet containing the data following an encoded symbol
separator character.
2
Data packet containing the data following an escape
mechanism character. The data packet does not support the
ECI protocol.
