RS30 Mobile Computer Reference Manual
No. Description No. Description
1 Proximity+ALS Sensor Hole 2 Receiver
3 Status LED 4 Touchscreen
5 Power Button 6 Micro USB Port
7 Side Key 8 Speaker
9 Wristband Slot 10 Charging Pins
11 Headset Jack 12 Scan Window
13 Camera Flash 14 Camera
15 Battery Cover Latch 16 Battery Cover
17 NFC Detection Area 18 Volume Buttons
19 Side Key 20 Wristband Slot
