3.5.15.- MEASURING SINGLE-PHASE NETWORKS, PHASE TO NEUTRAL, WITH A 2-WIRE
CONNECTION, CVM-C10-FLEX MODEL.
Measurement system:
LOAD
Power
Supply
VL1 N
L1
N
POWER SUPPLY
INPUTS
A(+) B(-)
GND
RS485
300V
~
Ph-NPh-Ph
520V
~
NV
L3L2
V
L1
V
I1 I2
VL1 N
a b
A B
L1 L2 L3 LN C SHLD
L1
C
SHLD
FLEX-MAG
(100mV~ )
Figure 18: Measuring Single-Phase Networks, phase to neutral, with a 2-wire connection, CVM-C10-FLEX model.
It is mandatory connect the SHLD terminal of the probe.
29
Instruction Manual
CVM-C10
