Circutor CVM-C10 User Manual

5.- TECHNICAL FEATURES
AC Power supply
Rated voltage
95 ... 240 V
~ ± 10%
Frequency 50 ... 60 Hz
Consumption 4 ... 6 VA
Installation category CAT III 300 V
DC Power supply
Rated voltage 105 ... 272 V
± 10% 23 ... 109 V ± 10%
(1)
Consumption 2 ... 6 W 3.5 ... 3 W
Installation category CAT III 300 V
(1)
Only available for references M5591100F0000, M5592100F0000, M5592100F0V00, M5594200F00000 and
M5596100F0000.
Voltage measurement circuit
Rated voltage (Un) 300 V
Ph-N, 520 V Ph-Ph
Voltage measurement margin 5 ... 120% Un
Frequency measurement margin 45 ... 65Hz
Input impedance 440 kΩ
Min. voltage measurement (Vstart) 10 V
Installation category CAT III 300 V
Current measurement circuit
CVM-C10-FLEX Measure through Rogowski sensors, see Table 2
Nominal current (In)
CVM-C10-ITF
CVM-C10-ITF-IN
CVM-C10-MC
.../5A o .../1 A .../0.250 A
CVM-C10-mV CVM-C10-FLEX
.../0.333 V .../100 mV ~
Neutral current measurement
CVM-C10-ITF-IN CVM-C10-FLEX
.../5A o .../1 A .../100 mV ~
Current measurement margin
CVM-C10-ITF
CVM-C10-ITF-IN
CVM-C10-MC
2 ... 120% In 2 ... 120% In
CVM-C10-mV CVM-C10-FLEX
2 ... 120% In 0.2 ... 200% In
Maximum current, impulse < 1s
CVM-C10-ITF
CVM-C10-ITF-IN
CVM-C10-MC
100 A 100 A
CVM-C10-mV CVM-C10-FLEX
1.2 In 2 In
Min. current measurement (Istart)
CVM-C10-ITF
CVM-C10-ITF-IN
CVM-C10-MC
10 mA
MC1 MC3
0.25 A 0.1 A
CVM-C10-mV CVM-C10-FLEX
6.66 mV
0.2 mV
~
87
Instruction Manual
CVM-C10
