Table 8 (Continuation) : Measuring parameters of the CVM-C10.
Parameter Units
Phases
L1-L2-L3
Total
III
N
Harmonic Breakdown - Current
(up to the 31st order harmonic)
harm V

Total Active Energy M/kWh

Total Inductive Reactive Energy M/kvarLh

Total Capacitive Reactive Energy M/kvarCh

Total Apparent Energy M/kVAh

Active Energy Tariff 1 M/kWh

Inductive Reactive Energy Tariff 1 M/kvarLh

Capacitive Reactive Energy Tariff 1 M/kvarCh

Apparent Energy Tariff 1 M/kVAh

Active Energy Tariff 2 M/kWh

Inductive Reactive Energy Tariff 2 M/kvarLh

Capacitive Reactive Energy Tariff 2 M/kvarCh

Apparent Energy Tariff 2 M/kVAh

Active Energy Tariff 3 M/kWh

Inductive Reactive Energy Tariff 3 M/kvarLh

Capacitive Reactive Energy Tariff 3 M/kvarCh

Apparent Energy Tariff 3 M/kVAh

Maximum Current Demand A
 
Maximum Demand of Active power M/kW
 
Maximum Demand of Apparent Power M/kVA
 
Parameter Units Tariff: T1-T2-T3 Total
No. of hours hours
 
Cost COST
 
CO
2
Emissions kgCO
2
 
4.2.- KEYBOARD FUNCTIONS
The CVM-C10 has 3 keys that allow you to browse between the various screens and program
the device.
Key functions on measuring screens (
Table 9):
Table 9: Key functions on measuring screens.
Key Short keystroke
Long keystroke
(2 s)
Previous screen Display of minimum value
Next screen Display of maximum value
Browsing the different proles
(analyzer, user, e3)
Accessing the programming
menu
32
CVM-C10
Instruction Manual
