The variable format is shown in Table 43:
Table 43:Variable format: Status of digital inputs.
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 0 0 0 0 0
Input 2
0: OFF
1: ON
Input 1
0: OFF
1: ON
4.10.3.7.15. Digital outputs
Reading the status of the digital outputs.
The 0x04 function is implemented for this variable.
Table 44:Modbus memory map: Status of the digital outputs
Status of the digital outputs
Variable Address Default value
Status of the digital outputs 4E21 -
The variable format is shown in Table 45:
Table 45:Variable format: Status of the digital outputs.
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 0 0 0
Output
4
0: OFF
1: ON
Output
3
0: OFF
1: ON
Output 2
0: OFF
1: ON
Output 1
0: OFF
1: ON
4.10.3.7.16. Communications
Table 46:Modbus memory map: Communications
Communications
Configuration variable Address Valid data margin
Default
value
Protocol 2742
0 : Modbus
1: Bacnet
0
Modbus and BACnet: Peripheral number 2743 0 - 255 1
Modbus : Transmission speed 2744 0: 9600 - 1:19200 0
Modbus : Parity 2745
0: No parity
1: Odd parity
2: Even parity
0
Modbus : Data bits 2746
0 : 8 bits
1: 7 bits
0
Modbus : Stop bits 2747
0 : 1 stop bit
1: 2 stop bits
0
BACnet: Device ID 2EE0- 2EE1 0- 999999 -
BAcnet: MAC 2EE2 0- 255 2
4.10.3.7.17. Password conguration
These variables allow you to lock or unlock access to the programming menu, and also allow
you to change the password code. The password code may only be changed through this com-
mand.
The device does not need you to enter the old password in order for it to record the new one; it
records the new one directly without any verication.
