Cirris 4200 Series User Manual
13. Components (New test program)
Components can be automatically added to a test program during the Learn process for a new test program. If not origi-
nally Learned, the test program can be edited wtih a text editor. The 4200 Series can Learn the following components:
● Resistors
● Capacitors
● Diodes
● Four-Wire
● Twisted Pair – 4250 only
Select the required component to add it to the test program.
● On: The component type will be Learned by the tester and
added to the test program.
● O: The test program will not include the component.
Although tolerences that are automatically set during the Learn, review the test program to verify that the measured
value of the components is the nominal vaue. One way to review the values is through a text editor such as in Cirris Hub
Software.
Edit Learn Components
