28. Factory Defaults
The following table lists the settings for the 4200 Series testers and their corresponding factory defaults.
Preferences
Low Voltage Start Cable Attach
High Voltage Start Start Button
HV Auto Start Delay 1.0 S
Intermittents Test For Duration
Intermittents Test Duration 2 S
Enter Lot ID OFF
External Start Switch OFF
External Safety Switch OFF
LV Settings
Connection Resistance 10.0 ohm
LV Insulation Resistance 100 k ohm
High Voltage - 4250 only
High Voltage ON
HV Basic Settings
High Voltage 50 V
Insulation Resistance 5 M ohms
Dwell Time 2 mS
HV Advanced Settings
DW Voltage 50 V
DW Max Current 0.1 mA
DW Dwell Time 10 mS
