Cirris 4200 Series User Manual
3. Hardware Setup
3.1 You should have received
● Cirris 4200 Low Voltage or 4250 High Voltage Cable Tester
● Power cord
● PC (USB A to USB B) cable
● Probe
● Antenna
● USB ash drive containing software/documentation
● Optional: Adapters, expansion boxes, tilt stands, and other accessories.
●
3.2 Front of Tester
a. 7" full-color graphical display with capacitive touch screen (800 x 480 pixel resolution).
b. Cirris adapter system creates an easy xturing setup system.
c. High voltage warning symbol
d. Handles for portability
a b
c
d
