Cirrus Design Section 7
SR22T Airplane and Systems Description
P/N 13772-003 7-63
Figure 7-14
Optional Air Conditioning System
RAM AIR RAM AIR
CROSSOVER TUBE
PANEL AIRFLOW
FOOT-WARMER
DIFFUSER
DISTRIBUTION
MANIFOLD
CONTROL PANEL
AIR
GASPER
AIR FLOW VALVE
RAM AIR
FRESH AIR
VALVE
HOT AIR VALVE
S
P
SP
EVAPORATOR
ASSEMBLY
COMPRESSOR
RECIRCULATION
CHECK VALVE
CONDENSER
ASSEMBLY
NOTE: llustration depicts maximum cabin
cooling airflows and selector settings
while on ground or warm outside air
temperatures.
FLOOR
AIRFLOW
WINDSHIELD
DIFFUSER
SR22_FM07_3262
MIXING
CHAMBER
SERVO MOTOR
CONTROLLER
TEMPERATURE
SENSOR
Revision 1

Cirrus DESIGN SR22T Specifications

General

Manufacturer	Cirrus Aircraft
Model	SR22T
Seating Capacity	5
Engine	Continental TSIO-550-K
Horsepower	315 hp
Avionics	Cirrus Perspective+ by Garmin
Type	Single-engine piston aircraft
Maximum Speed	213 knots
Cruise Speed	183 knots
Service Ceiling	25, 000 feet
Maximum Takeoff Weight	3, 600 lbs
Wingspan	38 feet 4 inches
Length	26 ft
Height	8 feet 11 inches
Safety Features	Cirrus Airframe Parachute System (CAPS)
Cabin Width	49 inches
Cabin Height	50 inches
