12 of 20 P/N 13772-115
Section 9 Cirrus Design
Supplements SR22 / SR22T
Figure - 2
SR22_FM09_1527
FINGER
STRAINER
FLUID
TANK
VENT
DRAIN
POROUS PANEL
POROUS PANELS
PROPORTIONING
UNIT
PROPORTIONING
UNIT
PROPORTIONING
UNIT
POROUS PANEL
POROUS PANELS
PROPORTIONING
UNIT
VENT
FITTING
METERING
PUMP
FILTER
SLINGER RING
System Schematic - Serials before G3 Wing
Revision 09: 12-17-10
