Procedure
Step 1
Plug the telephone line cord (RJ45 connector) into the phone jack at the base of the phone as shown in the
following image:
Figure 2: RJ45 Connector in the Phone Jack
Network Port on the Phone1
RJ45 Connector2
Cisco Unified SIP Phone 3905 Administration Guide for Cisco Unified Communications Manager 8.6 (SIP)
113
Cisco Unified SIP Phone 3905 Wall Mount
Install Phone on Wall Mount Plate
