Configuring sdr Listener Support
The MBONE is the small subset of Internet routers and hosts that are interconnected and capable of forwarding
IP multicast traffic. Other multimedia content is often broadcast over the MBONE. Before you can join a
multimedia session, you need to know what multicast group address and port are being used for the session,
when the session is going to be active, and what sort of applications (audio, video, and so forth) are required
on your workstation. The MBONE Session Directory Version 2 (sdr) tool provides this information. This
freeware application can be downloaded from several sites on the World Wide Web, one of which is
http://www.video.ja.net/mice/index.html.
SDR is a multicast application that listens to a well-known multicast group address and port for Session
Announcement Protocol (SAP) multicast packets from SAP clients, which announce their conference sessions.
These SAP packets contain a session description, the time the session is active, its IP multicast group addresses,
media format, contact person, and other information about the advertised multimedia session. The information
in the SAP packet is displayed in the SDR Session Announcement window.
Enabling sdr Listener Support
By default, the switch does not listen to session directory advertisements.
Beginning in privileged EXEC mode, follow these steps to enable the switch to join the default session
directory group (224.2.127.254) on the interface and listen to session directory advertisements. This procedure
is optional.
This procedure is optional.
SUMMARY STEPS
1.
configure terminal
2.
interface interface-id
3.
ip sap listen
4.
end
5.
show running-config
6.
copy running-config startup-config
DETAILED STEPS
PurposeCommand or Action
Enters the global configuration mode.configure terminal
Example:
Switch# configure terminal
Step 1
Specifies the interface to be enabled for sdr, and enters
interface configuration mode.
interface interface-id
Example:
Switch(config)# interface
Step 2
Catalyst 2960-XR Switch IP Multicast Routing Configuration Guide, Cisco IOS Release 15.0(2)EX1
100 OL-29426-01
Configuring IP Multicast Routing
Configuring sdr Listener Support

Cisco Catalyst 2960-XR Specifications

General

Stacking Bandwidth	80 Gbps
Layer Support	Layer 2 and Layer 3
Jumbo Frame Support	9198 bytes
RAM	512 MB
Input Voltage	100-240V AC
Model	Catalyst 2960-XR
Uplink Interfaces	4 x 1G SFP or 2 x 10G SFP+
Downlink Interfaces	24 or 48 x Gigabit Ethernet ports
Power Supply	Internal
MAC Address Table Size	16, 000 entries
PoE	Available on PoE models
Weight	4.5 kg
Features	energy efficiency
Stacking	Up to 8 switches
Operating Temperature	0 to 45°C
